Electric Golf Cart With 30% Gradeability AC Motor And Hydraulic Brake For Golf Courses And Tourist Resorts

Electric Golf Cart With 30% Gradeability AC Motor And Hydraulic Brake For Golf Courses And Tourist Resorts

ब्रांड नाम:	LANGJIE
मॉडल संख्या:	ईडीए-ई918-एल2+2
न्यूनतम आदेश मात्रा:	1 इकाई
कीमत:	Negotiate
भुगतान की शर्तें:	टी/टी
आपूर्ति करने की क्षमता:	300 यूनिट/ माह

विस्तार से जानकारी

उत्पाद का वर्णन

विस्तार से जानकारी

उत्पत्ति के प्लेस:

गुआंग्डोंग

प्रमाणन:

CE, DOT

दस्तावेज़:

उत्पाद पुस्तिका पीडीएफ

कलपुर्जों के नाम:

इलेक्ट्रिक हुटिंग कार

अधिकतम गति:

20-30 किमी/घंटा

वोल्टेज:

48V

यात्री क्षमता:

2+2 सीटें

चढ़ने की क्षमता:

30%

टर्निंग रेडियस:

3.5 मीटर

मोटर:

48V/5KW एसी मोटर

बैटरी:

8V /150AH*6PCS

पैकेजिंग विवरण:

गैर पैकिंग या स्टील पैकिंग

आपूर्ति की क्षमता:

300 यूनिट/ माह

प्रमुखता देना:

30% Gradeability Electric Golf Cart

उत्पाद का वर्णन

Electric Golf Cart With 30% Gradeability AC Motor And Hydraulic Brake For Golf Courses And Tourist Resorts

Electric Golf Car 2+2 Seats MODEL EDA-E918-L2+2

HS CODE	8703101900
Qty/20'GP (Assembled)	2 UNITS
Qty/40'HQ (Assembled)	4 UNITS
Qty/20'GP (Disassembled)	7 UNITS
Qty/40'HQ (Disassembled)	18 UNITS

Technical Specifications

Passenger capacity	4 seats
Max.Speed	18-40km/h
Range (loaded)	70km-90km (level road)
Climbing Ability	30%
Braking Distance	<6m
Min.Turning Radius	3.5m
Recharge time	8~10h
L×W×H	292013152140 mm
F/R Tread	980mm/1085mm
Axle Distance	1690mm
Curb Weight	600kg
Max. loading	340kg

Key Components

Motor	48V/5KW AC motor
Controller	48V
Battery	Maintenance-free battery 8V /150Ah*6PCS
Body & Roof	Automobile special PP material injection molded parts / Integrated molding roof
Windshield	Foldable windshield
Seats	Ergonomic seat, leather fabric
Tire	23*10.5-12 Aluminum steel rim

Advanced Features

Chassis: Robotic welding with high-end coating processing, super strong, no rust
Front Suspension: Double swing arm independent front suspension + spiral spring + cylinder hydraulic shock absorption
Rear Suspension: Overall rear axle, speed ratio 12.49:1 spiral spring shock absorption + cylinder hydraulic shock + rear stabilizer bar
Lighting System: LED front combination light and rear taillight with multiple functions
Brake System: Double-loop four-wheel hydraulic brake, four-wheel disc brake + electronic brake parking
Steering System: Double gear rack steering with automatic clearance compensation
Dashboard: Injection molding instrument panel with multiple functions including USB power supply

Color Options

Standard seat colors: Black, Beige

Optional colors: Ocean Grey, Sapphire blue, Pearl black, Pearl White, Apple Green, Matt Black, Dark Green, Orange, Red

Roof: Black

Manufacturing Capabilities

Monthly production capacity: 100 units

Professional workforce: 350 employees including quality inspectors

Robust iron frame packaging for transit protection

Global shipping experience to multiple countries including USA, Canada, Australia, and European nations
